CDC series horizontal lathe machine

time:2017-03-19
CDC series horizontal lathe machine

Model

CD6240C

CD6250C

CD6260C

Swing over bed

400mm

500mm

600mm

Swing over cross slide

225mm

325mm

360mm

Swing over gap

530mm

630mm

730mm

Effective length of gap

260mm

Max. Length of workpiece

1000/1500/2000/3000mm

Width of bed

330mm

Spindle bore

ISO-C8 or ISO-D8

Spindle bore size

80mm

Speed range

24-1600rpm, 15 steps

Longitudinal feed range

66 kinds, 0.072-4.038mm/rev.

Cross feed range

66 kinds, 0.036-2.019mm/rev.

Metric thread range

66 kinds, 0.5-28mm

Inch thread range

66 kinds, 56-1inch

Module thread range

33 kinds, 0.5-3.5mm

Diameter thread range

33 kinds, 56-8dp

Diameter of tailstock sleeve

65mm

Tailstock taper

MT5

Tailstock travel

120mm

Power of main motor

5.5KW or 7.5KW

Power of feed motor

120W

Power of coolant motor

0.125KW

Package size

2420/2920/3460/4720×1150×1800mm
